Part name
|
Spares Number |
Qty |
Price in US$ |
| Screens and screen parts |
| |
CSTN Backlight Inverter Board
|
199223-001 |
5 |
$30.00 |
| |
Display enclosure kit 4/25
|
197237-001 |
5 |
$20.00 |
| |
Display bezel 4/25
|
197344-001 |
5 |
$10.00 |
| |
Display bezel 4/33c
|
199260-001 |
5 |
$10.00 |
| Chassis Components |
| 1 |
Base assembly (Base Enclosure)
|
197253-001 |
5 |
$25.00 |
| 3 |
Door assembly
|
197239-001 |
3 |
$10.00 |
| 9 |
Trackball cable and speaker assembly
|
197312-001 |
5 |
$20.00 |
| 10 |
Trackball assembly
|
197286-001 |
4 |
$10.00 |
| 11 |
Hard drive bracket
|
197236-001 |
0 |
$10.00 |
| 13 |
CPU cover (Keyboard Enclosure)
|
197311-001 |
5 |
$10.00 |
| 14 |
Keyboard |
190620-001 |
6 |
$25.00 |
| 14 |
Keyboard (not sure why this number is
here->)
|
199276-001 |
|
$25.00 |
| 15 |
PCMCIA Eject Assembly
|
197314-001 |
5 |
$25.00 |
| System Board |
| 2 |
System board, 4MB w/o PCMCIA ejector,
Aero 4/25
|
197241-001 |
5 |
$40.00 |
| 2 |
System board, 4MB w/o PCMCIA ejector,
Aero 4/33c
|
199222-001 |
1 |
$40.00 |
| 12 |
System ROM (shipped on the above board)
|
197227-003 |
5 |
Included |
| Power Supply / Batteries |
| 4 |
Power Supply DC/DC
|
190521-001 |
4 |
$30.00 |
| |
Auto Adapter
|
190551-001 |
0 |
n/a |
| |
NiMH Battery Pack
|
190626-001 |
0 |
n/a |
| |
NiMH Battery Pack
|
190697-001 |
0 |
n/a |
| Drives |
| 5 |
Model 250MB
|
199233-001 |
0 |
n/a |
| 5 |
Model 170MB
|
190661-001 |
0 |
n/a |
| 5 |
Model 84MB
|
190660-001 |
0 |
n/a |
| |
External PCMCIA Diskette Drive
|
190563-001 |
0 |
n/a |
| Memory |
| 6 |
4MB Memory Expansion Board
|
190565-001 |
0 |
n/a |
| 6 |
8MB Memory Expansion Board
|
190596-001 |
0 |
n/a |
| Cables |
| |
Display cable 4/25m
|
197238-001 |
1 |
$25.00 |
| |
Display cable 4/33c
|
199258-001 |
0 |
$25.00 |
| Miscellaneous |
| |
Input Video Adapter (?)
|
197364-001 |
0 |
$20.00 |
| |
4/25 & 4/33C Display Hardware Kit
(Screw assortment for Aero repair stations)
|
197316-001 |
0 |
email me |
| |
3/20 & 3/25 Screws 2.5x.45 (Qty
25)
(Screws to hold base together)
|
142966-001 |
0 |
n/a |
| |
4/25 & 4/33C Operations Manuals
|
|
0 |
n/a |
